Real-time monitoring of cooking fume particulate concentration
Intelligent dust source identification technology
Lens self-cleaning technology, long-term protection
Side-flow design, unaffected by sampling flow rate
Built-in mist removal device, unaffected by water vapor
Service life over 3 years under power-on conditions
Detection Principle: Mie Spherical Scattering Principle
Detection Particle Size Range: 0.1~10 μm
PM2.5 Output Consistency: 100~500ug/m3 max allowable error ±10%
PM2.5 Output Consistency: <100 ug/m³ max allowable error ±10ug/m3
PM2.5 Output Range: 0~1000
Working Conditions: -10~50℃, 0~95% RH
Storage Conditions: -20~65℃, 0~95% (Non-condensing)
Working Voltage: DC 5V ±5% (Power Ripple 50mV Max)
Working Current: ≤60 mA
Signal Output: PWM, UART
Mean Time Between Failures: ≥3 years
Product Size: W42*H35.5*D23.5(mm)
