Consistency output less than ±8-10%
Operation without abnormal noise, long life
Real-time response, continuous collection for 30,000-50,000 hours
Simultaneous output of PM1.0, PM2.5, PM10, temperature/humidity, VOC
Detection Principle: Mie Spherical Scattering Principle
Detection Particle Size Range: 0.1~10 μm
PM2.5 Output Range: 0~1000
Working Conditions: -10~70℃, 0~95% RH
Storage Conditions: -40~80℃, 0~95% (Non-condensing)
Working Voltage: DC 5V±5% (Power Ripple 50mV Max)
Working Current: ≤80 mA
Standby Current: ≤0.5mA
Signal Output: PWM, UART
Mean Time Between Failures: ≥5 years
Product Size: W50*H38*D21(mm)
PM2.5 Output Consistency: >100 ug/m³ max allowable error ±10%
PM2.5 Output Consistency: <100 ug/m³ max allowable error ±10ug/m³
LD12 series is a high-temperature resistant, long-life laser dust sensor. Based on optical scattering and Luftmy's unique dust source identification technology, it accurately calculates suspended particles of different sizes.
The LD11 series is a high-temperature resistant, long-life, ultra-thin laser dust sensor. Based on the principle of optical scattering and combined with LUFTMY's unique dust source intelligent identification technology, it can accurately detect and calculate the number of particles of different sizes in a unit volume across various environments. Through mathematical algorithms and scientific calibration, it achieves accurate PM2.5 mass concentration output. The full metal shell effectively shields electromagnetic interference, providing excellent anti-interference performance.
The LD10 laser dust sensor series is a high-temperature resistant, long-life laser dust sensor. Based on optical scattering and LUFTMY's unique dust source identification technology, it accurately detects particle counts across sizes in unit volumes. It outputs accurate PM2.5 concentrations via mathematical algorithms and scientific calibration. The conductive shell effectively shields electromagnetic interference.
The LD09 series is a high-temperature resistant, long-life, ultra-thin laser dust sensor. Based on the principle of optical scattering and combined with LUFTMY's unique dust source intelligent identification technology, it can accurately detect and calculate the number of particles of different sizes in a unit volume across various environments. Through mathematical algorithms and scientific calibration, it achieves accurate PM2.5 mass concentration output. The full metal shell effectively shields electromagnetic interference.
