Consistency output less than ±8-10%
Operation without abnormal noise, long life
Real-time response, continuous collection for 30,000-50,000 hours
Simultaneous output of PM1.0, PM2.5, PM10, temperature/humidity, VOC
Detection Principle: Mie Spherical Scattering Principle
Detection Particle Size Range: 0.1~10 μm
PM2.5 Output Range: 0~1000
Working Conditions: -10~70℃, 0~95% RH
Storage Conditions: -40~80℃, 0~95% (Non-condensing)
Working Voltage: DC 5V±5% (Power Ripple 50mV Max)
Working Current: ≤80 mA
Standby Current: ≤0.5mA
Signal Output: PWM, UART
Mean Time Between Failures: ≥5 years
Product Size: W50*H38*D21(mm)
PM2.5 Output Consistency: >100 ug/m³ max allowable error ±10%
PM2.5 Output Consistency: <100 ug/m³ max allowable error ±10ug/m³
LF10 is a sensor that does not require an internal fan; its driving air source comes from the host device, improving on defects caused by fans. It features a high-intensity uniform light sensing area within a scattering chamber.
