Consistency output less than ±8-10%
Patented technology, accuracy up to 0.1um
Real-time response, continuous collection for 30,000-50,000 hours
Ultra-low current, 30-50% lower than peers
Simultaneous output of PM1.0, PM2.5, PM10
Service life over 8 years under power-on conditions
Detection Principle: Mie Scattering Principle
Detection Particle Size Range: 0.5~10 μm
PM2.5 Output Range: 0~1000
Operating Conditions: -10~70℃, 0~95% RH
Storage Conditions: -40~80℃, 0~95% (Non-condensing)
Working Voltage: DC 5V±5% (Power ripple 50mV Max)
Working Current: ≤80 mA
Standby Current: ≤0.5mA
Signal Output: PWM, UART
Mean Time Between Failures (MTBF): ≥5 years
Product Dimensions: W38*H35*D12 (mm)
PM2.5 Output Consistency: >100 ug/m³ max allowed error ±10%
PM2.5 Output Consistency: <100 ug/m³ max allowed error ±10ug/m³
The LD19 is a high-precision particulate matter concentration sensor based on the Laser Mie Scattering theory. It can continuously collect and calculate the number of suspended particles of different sizes in the air per unit volume—namely the particulate matter concentration distribution—and convert this into mass concentration, outputting it via a universal digital interface. This sensor can be embedded in various instruments or environmental improvement equipment related to suspended particulate concentration to provide timely and accurate data.
LD12 series is a high-temperature resistant, long-life laser dust sensor. Based on optical scattering and Luftmy's unique dust source identification technology, it accurately calculates suspended particles of different sizes.
The LD11 series is a high-temperature resistant, long-life, ultra-thin laser dust sensor. Based on the principle of optical scattering and combined with LUFTMY's unique dust source intelligent identification technology, it can accurately detect and calculate the number of particles of different sizes in a unit volume across various environments. Through mathematical algorithms and scientific calibration, it achieves accurate PM2.5 mass concentration output. The full metal shell effectively shields electromagnetic interference, providing excellent anti-interference performance.
The LD10 laser dust sensor series is a high-temperature resistant, long-life laser dust sensor. Based on optical scattering and LUFTMY's unique dust source identification technology, it accurately detects particle counts across sizes in unit volumes. It outputs accurate PM2.5 concentrations via mathematical algorithms and scientific calibration. The conductive shell effectively shields electromagnetic interference.
