Resolution up to 1ppb
Highly integrated module, simultaneously outputs formaldehyde, VOC, TVOC and other parameters
Full-range temperature and humidity compensation
Unique dual-channel design, alcohol cross-interference <1%
Alcohol-resistant, fast recovery time
Multiple communication options available: UART, I2C, PWM
Detection Principle: Metal Oxide Semiconductor (MOx)
Target Gases: Formaldehyde, Benzene, Carbon Monoxide, Hydrogen, Alcohol, Ammonia, Smoke, etc.
Response Time: ≤10s
Preheating Time: 180s
Operating Conditions: -10~60℃, 5~95%RH (non-condensing)
Storage Temperature: -10~65℃ (no frost)
Storage Conditions: -40~85℃; 5~95%RH (non-condensing)
Operating Voltage: DC5V ±0.2V
Communication Methods: PWM, UART, I2C
Standby Current: ≤0.5mA
Signal Output: PWM, UART
Mean Time Between Failures (MTBF): ≥5 years
Product Dimensions: W24 × H20 × D5 (mm)
