Comprehensive and reliable evaluation of temperature, humidity, and air quality
Built-in temperature compensation and humidity compensation algorithms
High sensitivity and fast response
Very low power consumption (< 66 mW)
Compact size (17.8 mm × 15.2 mm × 2.5 mm)
Intelligent automatic baseline calibration
Baseline value can be reset, and baseline storage is configurable
Robust design with excellent long-term stability
Highly flexible assembly options and communication interfaces
Sensing principle: MEMS metal oxide semiconductor sensor
Preheating time: 3 minutes
Communication protocol: I²C, UART
Calibration method: Intelligent baseline calibration, baseline value stored during power-off (configurable)
Supply voltage: 3.3V ± 0.1V, max. 20 mV ripple
Power consumption: Max. 66 mW @ 3.3 VDC (20 mA)
Measurement interval: 1 sec.
Operating temperature: -10 ~ +60 ℃
Operating humidity: 5 ~ 95% RH, non-condensing
Storage temperature: -40 ~ +85 ℃
Storage humidity: 5 ~ 95% RH, non-condensing
CO₂ detection range: 400–5000 ppm
TVOC detection range: 0 – 50,000 µg/m³
HCHO detection range: 0 – 2000 µg/m³
Temperature measurement range: -40 ~ 125 ℃
Humidity measurement range: 0 ~ 100% RH
